anti-EST

Prunella vulgaris

PV has been extensively used in China both independently and as a part of a multi-modal approach to treat cancer patients with standard chemotherapy. It appears to target multiple signaling pathways and has a complex mechanism of action. The complexity of the herb may be a key element of its therapeutic or preventive effectiveness (Huang et al., 2015).

Prunella vulgaris (PV) has been shown to exert anti-estrogenic effects. The main components are rosmarinic acid, caffeic acid, ursolic acid (UA), oleanolic acid, hyperoside, rutin, and betulinic acid (BA). PV is capable of suppressing oestrogen response element (ERE)-dependent luciferase activity and expression of oestrogen-responsive genes in response to exposure to oestradiol, further supporting the suppressive role of these compounds in oestrogen-induced signaling (Kim et al., 2014).

Kim et al., (2014) isolated the constituents of P. vulgaris and tested their individual anti-estrogenic effects. Rosmarinic acid, caffeic acid, ursolic acid (UA), oleanolic acid, hyperoside, rutin and betulinic acid (BA) were isolated from the flower stalks of P. vulgaris var. lilacina Nakai (Labiatae).

Among these constituents, UA and BA showed significant anti-estrogenic effects, measured as a decrease in the mRNA level of GREB1, an oestrogen-responsive protein; the effects of BA were stronger than those of UA. UA and BA were capable of suppressing oestrogen response element (ERE)-dependent luciferase activity and expression of oestrogen-responsive genes in response to exposure to oestradiol, further supporting the suppressive role of these compounds in oestrogen-induced signaling.

However, neither UA nor BA was capable of suppressing oestrogen signaling in cells ectopically overexpressing oestrogen receptor α (ERα). Furthermore, both mRNA and protein levels of ERα were reduced by treatment with UA or BA, suggesting that UA and BA inhibit oestrogen signaling by suppressing the expression of ERα. Interestingly, both compounds enhanced prostate-specific antigen promoter activity.

By screening multiple herbs using the endometrial cancer cell line, ECC-1, and an alkaline phosphatase detection assay, Collins et al., (2009) found that PV displayed significant anti-estrogenic activity. The possible usefulness of anti-estrogenic activity using was investigated both in vitro and in vivo models of endometrial function. Using the well-differentiated, hormone-responsive endometrial cell line, ECC-1, PV extract, at concentrations that were not toxic to the cells, significantly reduced alkaline phosphatase activity and cell proliferation in response to oestrogen in a dose-dependent manner.

The extracts of Prunella vulgaris have multi-target and multi-pathway effects on tumors and its possible mechanisms may be due to the regulation of steady state of calcium ion, cell cycle and its steady state and the inhibition of tumor cell proliferation and metastasis (Wang et al., 2014).

Scientific Research

Characterization of Antioestrogenic Activity of the Chinese Herb, Prunella vulgaris, Using In Vitro and In Vivo (Mouse Xenograft) Models

Collins NH, Lessey EC, DuSell CD, et al. Biol Reprod. Feb 2009; 80(2): 375–383. doi: 10.1095/biolreprod.107.065375

Prunella vulgaris (PV), a commonly used Chinese herb, also known as Self-heal, has a wide range of reported medicinal activities. By screening multiple herbs using the endometrial cancer cell line, ECC-1, and an alkaline phosphatase detection assay, we found that PV displayed significant anti-estrogenic activity. We investigated the possible usefulness of anti-estrogenic activity using both in vitro and in vivo models of endometrial function. Using the well-differentiated, hormone-responsive endometrial cell line, ECC-1, PV extract, at concentrations that were not toxic to the cells, significantly reduced alkaline phosphatase activity and cell proliferation in response to oestrogen in a dose-dependent manner. The expression of CYR61, an oestrogen-induced protein, was blocked in ECC-1 cells by both the anti-estrogenic ICI 182 780 and PV extract. Interestingly, PV extract did not appear to directly inhibit oestrogen signaling. Rather, we found that its activities were probably related to an ability to function as an aryl hydrocarbon receptor (AHR) agonist in ECC-1 cells. In support of this hypothesis, we noted that PV induced CYP1A1, CYP1B1, and AHR repressor expression in a dose-dependent manner—responses that were blocked by small interfering RNA treatment to reduce AHR and specific AHR antagonists. Ovariectomized immunodeficient RAG-2/gamma(c) knockout mice implanted with human endometrial xenografts developed implants only when treated with oestrogen. Mice treated with oestrogen and PV tea in their drinking water had fewer and smaller xenograft implants compared with their oestrogen-treated counterparts that drank only water (P < 0.05). Analysis of the resulting implants by immunohistochemistry demonstrated persistent oestrogen receptor (ER), but reduced proliferation and CYR61 expression. Mouse uterine tissue weight in PV-treated mice was not different from controls, and cycle fecundity of intact C57 female mice was unaffected by PV tea treatment. PV, or Self-heal, exhibits significant anti-estrogenic properties, both in vitro and in vivo. This activity is likely due to the ability of PV-activated AHR to interfere with oestrogen. This herb may be useful as an adjunct for the treatment of oestrogen-dependent processes like endometriosis and breast and uterine cancers. Full characterization of this herb will likely provide new insights into the crosstalk between AHR and ESR1, with potential for therapeutic applications in women.

Keywords: aryl hydrocarbon receptor, cell lines, Chinese herbs, endometriosis, endometrium, oestradiol, oestradiol receptor, female reproductive tract, herbal therapy, implantation

INTRODUCTION

Estrogens are steroid hormones with a variety of functions in many target tissues. While essential for reproductive function, the effects of oestrogen can be detrimental or support abnormal cell growth and/or differentiation. The actions of unopposed oestrogen or oestrogen in the face of progesterone (P) resistance can promote various gynaecologic disorders, including endometriosis, endometrial hyperplasia, and cancer. Understanding the role of oestrogen and other sex steroids will likely lead to an improved understanding of hormone-dependent diseases and their treatments.

Oestrogen REPLACE ment therapy has known risks and side effects that may mitigate its usefulness in menopause. Likewise, endogenous oestrogen in women of reproductive age may worsen or aggravate pre-existing conditions, such as endometriosis or uterine fibroids. Likewise, the use of anti-estrogens or medical suppression of oestrogen has proven benefit in gynaecology. However, in some cases, anti-estrogens, such as tamoxifen, that benefit target tissues like those of the breast, have unanticipated adverse effects on the endometrium. To this end, pharmaceutical companies have sought to develop selective oestrogen receptor modulators (SERMs) that might provide better activity profiles to selectively benefit bone and breast tissues, while not increasing risk of endometrial hyperplasia or cancer and heart disease. Finally, uterine receptivity may be compromised by excess oestrogen activity. Availability of an effective anti-estrogenic would likely have utility for the treatment of infertility and such defects in uterine receptivity caused by prolonged or exaggerated oestrogen action.

There is increasing interest in herbal and botanical remedies in gynaecology. For a variety of reasons, many more women are actively seeking natural or non-traditional medicinal approaches to treat a wide variety of complaints and conditions. Recently, the American College of Obstetrics and Gynaecology issued its first Clinical Update in Women's Health on the subject of complementary and alternative medicine, and the number of publications on gynaecologic uses of herbal therapies is rapidly expanding. The consumers of complementary and alternative therapies spend over three billion dollars annually. The use of herbal treatments with estrogenic activities has expanded as well, including primrose oil, black cohosh, and soy protein. Many medical practitioners are unaware of the potential drug interactions involving alternative medicines, and many patients do not tell their physicians that they are taking herbal remedies. While some randomized controlled trials involving alternative medicine are occurring, there remain many herbal therapies that have not been scientifically studied.

In this study, we investigated the botanical herb Prunella vulgaris (PV), a common plant found in Europe and Asia with a long history of use as a remedy for multiple human conditions. This herbal remedy contains antioxidant and antimicrobial properties, and has been used to treat dysmenorrhea. During a screening of multiple Chinese herbs, we found that extracts of this plant have anti-estrogenic activities, the mechanism(s) of which we probe in this study using both cellular and in vivo models of oestrogen action. Based on recent studies suggesting the involvement of the aryl hydrocarbon receptor (AHR) as an anti-oestrogen in the action of herbs, supplements, and environmental toxins, and the link between the AHR agonist dioxin and endometriosis, we investigated the potential interactions of PV with this receptor to better understand its mechanism of action.

MATERIALS AND METHODS

Herb Extraction

PV was purchased along with other herbal remedies at a local Chinese medicine distributor in Greenville, South Carolina (Table 1). Initially, all herbs were extracted at room temperature with 100% methanol for 24 h at room temperature. The methanol was filtered and evaporated at 50°C. The residual extract was weighed and reconstituted in 100% ethanol. For animal studies, PV was brewed into a tea using 5-g/250 ml of distilled water.

TABLE 1.

Chinese herbs screened for estrogenic or anti-estrogenic properties.

Cell Proliferation Assay

Using a cell proliferation assay kit (CellTiter96 Aqueous One Solution Cell Proliferation Kit [Promega]), ECC-1 cells were cultured in phenol red-free Dulbecco modified Eagle medium/F12 (DME/F-12) media alone or in the presence of DES (10−8 M) or DES plus increasing concentrations of PV extract (wt/vol). Effect of PV extract was also compared to 100-fold excess of the anti-oestrogen ICI 182 780 (10−6 M). Cell number was estimated using a spectrophotometer plate reader at 490 nm using reagents per manufacturer's instructions.

Cell Viability Assay

Well-differentiated endometrial cancer cell line ECC-1 was used for these studies. This cell line was recently characterized by our laboratory [39]. The ECC-1 cells were prepared in 96-well plates with 2 × 104 cells per well in phenol red-free DME/F-12 medium. After 24 h, the medium was switched to the DME/F-12 phenol red-free medium containing the extracts, diethylstilbestrol (DES), or the pure anti-oestrogen Imperial Chemical Industries ICI 182 780 and was REPLACE d daily and assayed over time. Cell viability was determined using the Cell Titer-Blue TM Cell Viability Assay (Promega, Madison, WI). The medium was changed after 72 h, but only 100 μl was added with 20 μl of reagent provided with the kit and incubated for 2 h. The florescence in the substrate was then observed at 480 nm excitation and 530 nm emission by a fluorescence plate reader (LUMIstar; BMG Labtech, Durham, NC).

Alkaline Phosphatase Assay

To screen for estrogenic or anti-estrogenic activity, we used the alkaline phosphatase assay developed by Littlefield and colleagues [40] using ECC-1 cells. Medium was switched to phenol red-free DME/F-12 for 48 h before seeding in 96-well plates (BD Bioscience, Franklin Lakes, NJ). Unless otherwise stated, all reagents were obtained from Sigma (St. Louis, MO). The cells were washed twice with 1× PBS and then trypsinized until cells were dislodged and then resuspended in culture medium. Approximately 2 × 104 cells were added to each well with 200 μl medium and grown for 24 h. The cells then were switched to phenol red-free DME/F-12 medium containing specified concentrations of herbal extracts, DES or DES plus the anti-oestrogen ICI 182 780 for 72 h. The medium was changed daily. At the end of the treatment, the alkaline phosphatase assay was performed as previously described [40]. Cells were washed twice with 1× PBS and the plates were frozen for 10 min at −80°C and then thawed to lyse the cell membranes. A 20-μl aliquot of cold soluble substrate consisting of SigmaFast p-nitrophenyl phosphate tablets (Sigma) dissolved in deionized H2O was added to each well on ice. The substrate solution produced a yellow colour when alkaline phosphatase was present. After 1–3 h of incubation at room temperature, the absorbance was read in a plate reader at 405 nm (Bio-Rad, Hercules, CA). For comparison purposes, another endometrial cancer cell line (Ishikawa cells) was used.

Aryl Hydrocarbon Receptor Studies

General. β-Naphthoflavone, DMSO, and real-time quantitative PCR primers were purchased from Sigma. 3-methoxy-4-nitroflavone was a gift from Dr. Stephen Safe (Texas A&M University). Plasmid aryl hydrocarbon receptor response element-thymidine kinase-luc3 (AHRE-TK-luc3) was a gift from Dr. Alvaro Puga (University of Cincinnati).

Real-time PCR.

For RNA analysis, ECC-1 cells were seeded in six-well plates in phenol red-free media containing 8% charcoal-stripped serum, 1 mM sodium pyruvate, and 0.1 mM nonessential amino acids. After 48 h, cells were treated with the appropriate ligand. After 4 h, cells were harvested and total RNA was isolated using the Aurum Total RNA Mini Kit (Bio-Rad); 1 μg of RNA was reverse transcribed using the iScript cDNA synthesis kit (Bio-Rad). The Bio-Rad iCycler Realtime PCR System was used to amplify and quantitate levels of target gene cDNA. Quantitative PCR reactions were performed with 1 μl cDNA, 10 μM specific primers, and IQ SYBRGreen supermix (Bio-Rad). Data are normalized to the 36B4 housekeeping gene and presented as fold induction over vehicle. Data are the mean ± SEM from at least two independent experiments.

For small interfering (si) RNA experiments, ECC-1 cells were plated in the presence of 40 nM siAhR or siRNA control (Stealth siRNA; Invitrogen) using DharmaFECT-1 (Dharmacon, Lafayette, CO) as a transfection reagent. After 48 h, cells were treated with the indicated ligand for 4 h, then harvested and assayed for RNA expression, as detailed above.

Transient Transfection

For transient transfections, ECC-1 cells were plated in phenol red-free media containing 8% charcoal-stripped serum, 1 mM sodium pyruvate, and 0.1 mM nonessential amino acids in 24-well plates 24 h prior to transfection. Briefly, a DNA-lipofectin mixture (Invitrogen) containing a total of 3 μg of plasmid for each triplicate sample was added to the cells. Each triplicate sample contained 0.1 μg pCMV-βgal (Clontech, Mountainview, CA) and 2.9 μg AHRE-TK-luc3. Ligands were added to the cells 24 h after transfection, and cells were assayed following overnight treatment. Luminescence and β-galactosidase activity were measured on a Fusion luminometer (PerkinElmer, Waltham, MA). Results are expressed as fold activation over vehicle (normalized to β-galactosidase for transfection efficiency) for at least two independent triplicate experiments. Error bars indicate SEM.

Animal Protocols

Using approved Institutional Animal Care and Use Committee protocols at Greenville Hospital System, we purchased 32 RAG-2γ(c) knockout mice (C57BL/6J × C57BL/10SgSnAi[KO]γc[KO]Rag-2; Taconic, Germantown, PA) and then housed them under barrier husbandry conditions. Female RAG mice were ovariectomized using sterile technique and allowed to recover for at least 1 wk prior to further surgery. Additional intact C57 female mice (background strain) were purchased and allowed to mate with male C57 mice, while consuming either H20 or PV tea for 1 month prior to mating.

Human Endometrium

All human tissues were obtained after signed informed consent using protocols approved by the Institutional Review Committee at Greenville Hospital System (protocol no. 030607). Endometrial biopsies were obtained from cycling women during laparoscopy using a pipelle device, and the tissue was placed into Hams F12 medium for transport to the laboratory. In the laboratory, small samples (1 mm3) were dissected and placed into four separate positions in subcutaneous pockets in the abdomen of the ovariectomized, anesthetized RAG mice. The incisions containing the xenograft implants were closed with 5–0 Vicryl interrupted suture (Ethicon, Piscataway, NJ).

Hormone Treatments

Ovariectomized female mice used for the xenograft experiments were implanted with oestrogen (E2)-releasing pellets (Innovative Research of America, Sarasota, FL) or E2 plus P pellets. Some mice treated with oestrogen received PV tea as their sole source of drinking water. Treatments of xenograft containing mice extended for 4 wk, at which time animals were killed. We harvested uterine tissue and endometriotic xenograft tissue, at which time each was weighed and either snap frozen in liquid nitrogen or placed in 10% buffered formalin for subsequent analysis using immunohistochemistry.

Immunohistochemistry

Sections of endometriotic xenograft tissue were fixed in formalin and paraffin imbedded. Thin sections of representative blocks were immunostained for oestrogen receptor-alpha (ESR1), the oestrogen-sensitive protein, CYR61, and a marker of cell division, MKI67 (Ki67). Semiquantitative HSCORE was assigned in a blinded manner and compared between groups. The use of HSCORE has previously been validated as a semiquantitative assay for immunohistochemical staining [41]. The antibodies used are listed in Table 2.

TABLE 2.

List of antibodies used in the investigation of endometriotic implants.

Western Blot Analysis

ECC-1 cells were cultured in cell culture dishes (BD Bioscience) to about 80% confluence and treated for various amounts of time, ranging from 6 to 12 h, in treatment medium containing either DES, PV extract, ICI 182 780, or control medium. The cells were washed twice with cold 1× PBS. For each plate, 300 μl of 1× Protease Cocktail Inhibitor (Roche) diluted in RIPA buffer (1% NPH, 0.5% deoxycholate, 0.1% SDS in PBS) was added to each dish and incubated while shaking for 8 min or until cells were visibly dislodged. Cells were then scraped off the dish, removed, and sheared with a 20-gauge needle. After 30 min in an ice bath, the lysate was removed and centrifuged at 14 000 × g for 20 min at 4°C. The supernatant was removed and stored at −20°C. Total protein was measured by Bradford assay. Protein concentration was measured using BioProtein Assay reagent and measured with a spectrophotometer (Bio-Rad). Equal amounts of a standard protein concentration or biotinylated protein marker (Cell Signalling, Beverly, MA) with 2× sample buffer LAEMI were then loaded in a 4%–15% ready-made Tris-HCl polyacrymide gel (Bio-Rad). Gels were run at 100 V for approximately 1 h. After removing the gel, the proteins were transferred to a nitrocellulose membrane (GE Healthcare, Buckinghamshire, UK) for 45 min at 25 V with a semidry transfer cell (Bio-Rad). After blocking for 1 h with blotting-grade non-fat dry milk (Bio-Rad) in a shaking incubator, the membrane was incubated overnight with the primary CYR61 antibody or anti-β-actin in buffer (TBS-T [10% 10× TBS] and 5 ml Tween [BioRad]) at 4°C with continuous shaking. The membrane was then incubated with the matching mouse-HRP-conjugated anti-biotinylated secondary antibody (Cell Signalling) in buffer for 1 h while shaking. After 3 more 15-min TBS-T washes, 3 ml of equal amounts of ECL Western blotting reagent 1 and reagent 2 were added to the membrane for 1 min. The membrane was then developed on a single-coated film (Kodak, Rochester, NY). The protein on the membrane was stripped with stripping buffer consisting of 62.5 mM Tris-HCl, pH 6.8, 2% SDS (Bio-Rad), and 100 mM β-mercaptoethanol (EMD Biosciences, San Diego, CA), and probed for β-actin. β-Actin concentrations were determined by repeating the same method using the anti-β-actin antibody.

Statistical Analysis

Comparison between groups was performed using ANOVA with post hoc correction for multiple comparisons using Prism software version 4.0c (Graphpad Software, Inc., San Diego, CA). Two-tailed Student t-test was used for other comparisons. A 95% confidence interval was chosen as a determinant for significant differences (P < 0.05).

RESULTS

To determine if PV was toxic to the cells, we performed cell viability assays (Fig. 1A). In our study, PV extracts were toxic to cells at only the highest dose (500 μg/ml). The cells were viable following treatment up to 72 h with lower concentrations. At the final time point, none of the cell viability values were different, except at the 500 μg/ml dose when compared with controls (P < 0.05). To investigate the effect of PV on cell proliferation, we treated ECC-1 cells with different doses of PV up to 50 μg/ml. As noted in Figure 1B, while DES significantly increased cell proliferation (P < 0.001), PV significantly decreased cell proliferation at the highest dose (P < 0.01), exceeding the effect of ICI 182 780 on proliferation.

A) Cell viability Assay comparing DES and PV treatments over time (days). At time points 0, 1, 2, 3, and 4 days, cell viability was measured using the Cell Titer-Blue TM Cell Viability Assay. PV only reduced cell viability at the highest dose tested.

We previously performed a dose-response assay of oestrogen treatment using oestradiol and DES in ECC-1 and Ishikawa cells using the alkaline phosphatase assay (data not shown). Compared to oestradiol, DES stimulated the cells to a similar degree and was used because it lacks activity against the AHR and may be more stable than oestradiol in cell culture. The ECC-1 cells responded strongly to DES treatment in a dose-responsive manner. Peak activity was reached between 10−8 and 10−10 M DES, and concentrations above that were toxic to the cells. The Ishikawa cells responded to estrogens as well in the alkaline phosphatase assay, but with a reduced response [36]. Based on these favourable results, ECC-1 cells were chosen for all subsequent experiments. We show that DES significantly increased alkaline phosphatase activity (P < 0.001). Compared with the other herbs tested, PV was uniquely found to exhibit strong anti-estrogenic activity with a significant reduction in alkaline phosphatase activity.

Alkaline phosphatase assay in ECC-1 cells demonstrates an anti-estrogenic activity of the Chinese herbal remedy, PV. Note that at the dose of 50 μg/ml (DES + PV 50), the activity approached that of the anti-oestrogen ICI 182 780 (ICI). Data.

CYR61 is a cysteine-rich secreted protein and a member of the connective tissue growth factor family that has previously been shown to be rapidly induced in endometrial epithelium [14]. To investigate the anti-estrogenic effect of PV, ECC-1 cells were treated for 6 or 12 h with DES in the presence or absence of PV extract (50 μg/ml). Levels of CYR61 were induced by DES, and were highest at 6 h, but maximally reduced by concomitant treatment with either PV extract or ICI 182 780. Both ICI 182 780 and PV effectively reduced CYR61 expression in ECC-1 cells compared with controls (Fig. 3).

To investigate the effect of PV tea in an in vivo model of endometriosis, we used the previously validated RAG-2γ(c) knockout mouse model. As shown in Figure 4, endometrium placed subcutaneously grew under the influence of oestradiol pellets to a size that was visible under the skin. Harvested implants provided a histologic model for endometriosis and allowed us to compare the effects of oestrogen or oestrogen plus PV tea or P. In mice treated for 1 month with no treatment (control), oestradiol pellets alone (E2), E2 plus PV tea, or E2 plus P, there were statistical differences in the weight of implants recovered (Fig. 4). Few implants grew in the absence of oestrogen (control). While continuous treatment with E2 plus P resulted in a reduced number of surviving implants compared with E2 (P < 0.01). PV tea also reduced the average weight of implants compared with E2 alone (P < 0.05). The weight of the uteri recovered from each group of mice was not significantly different between groups.

Summary of the weight in grams of xenograft implants of endometrium placed in the RAG-2γ(c) knockout mice. Co-treatment with oestrogen (E2) and progesterone (E2 + P) yielded statistically fewer measurable implants (**P < 0.01). PV extract.

To investigate the biochemical effects of PV tea on endometriotic xenografts, we performed immunohistochemistry for the ESR1, CYR61, and a marker of cell proliferation, MKI67. Representative images are shown in Figure 5 for each marker in implants from oestrogen-treated (left column) versus oestrogen plus PV-treated (right column) animals. Using the semiquantitative HSCORE assessment of distribution and intensity of immunostaining for each marker protein in multiple implants from each group, we found that ESR1 was not different between groups, while MKI67 was significantly reduced (P < 0.01) compared with controls. CYR61, while lower in the PV-treated mice, did not reach statistical significance (P = 0.08).

Immunohistochemical appearance of endometriotic xenografts stained for ESR1, CYR61, and MKI67. While ESR1 was maintained, CYR61 and MKI67 were reduced in many of the implants from mice treated with PV tea. Original magnification ×200.

Summary of immunohistochemical data for ESR1, CYR61, and a marker of cell proliferation (MKI67) in xenografts harvested from mice treated with oestradiol (E2) or oestradiol and exposed to PV tea in the drinking water. While ESR1 was unchanged, both CYR61.

To test whether PV tea interfered with fertility, PV tea was also fed to intact C57 female mice in a continuous manner. After 2 wk of treatment, females were placed with intact male mice overnight. The number of pups per delivery was similar between PV-treated female mice and water-treated controls, suggesting that, despite its anti-estrogenic activity on xenograft tissues, the herb had little adverse effect on fertility.

Box and whisker plot of pregnancy outcome in mice treated with water or PV tea. Pregnancy in C57 mice treated for 2 wk with water (H2O) or PV (Tea) and then mated with fertile males overnight. The number of pups was not significantly different between.

There are many possible mechanisms by which a ligand can indirectly regulate ER activity, including crosstalk between the ER and the aryl hydrocarbon receptor (AHR) signaling pathways. We therefore investigated the possibility that a contributing factor to the anti-estrogenic activity of PV is its regulation of AHR. ECC-1 cells have previously been shown to exhibit AHR responsiveness, in addition to oestrogen and P responses [43]. Expression of AHR target genes, including CYP1A1, CYP1B1, and the AHR repressor was measured by quantitative RT-PCR in ECC-1 endometrial cells. ECC-1 cells were treated with vehicle, the AHR agonist, β-napthoflavone (BNF), or increasing concentrations of PV for 4 h. Data (mean ± SEM for three independent experiments) is presented as the fold induction over vehicle and shown in Figure 8, A–C. The stimulatory effect of PV was blocked by the anti-AHR ligand, 3-methoxy-4-nitroflavone (MNF), in a dose-responsive manner.

PV increases AHR target gene expression in a dose-dependent manner (A–C). Expression of AHR target genes was measured by qRT-PCR in ECC-1 endometrial cells. ECC-1 cells were treated with vehicle, 100 nM BNF, or increasing concentrations of PV.

To show that the increased expression of CYP1A1 by PV was dependent on AHR, we performed knockdown studies using siRNA against AHR. As shown in Figure 9, in the presence of the control vehicle, both BNF and PV stimulated CYP1A1, but this activity was abolished when cells were transfected with AHR siRNA. AHR was not affected by treatment with control vehicle or BNF and PV, but was down regulated by siRNA treatment. Finally, we demonstrated that, like the AHR agonist, BNF, PV activated an AHRE in a dose-dependent manner, and that this action was inhibited by the antagonist MNF .

Induction of CYP1A1 by PV is dependent on AHR expression. The requirement for AHR in PV-mediated induction of AHR (A) and CYP1A1 (B) was determined in ECC-1 cells. ECC-1 cells were transiently transfected with siRNA to AHR (siAhR) or with siRNA control.

PV activates an exogenous AHRE in endometrial cells. Transcriptional activity of AHR was examined in the human ECC-1 cell line. Cells were transfected overnight with an AHR-TK-luc3 reporter, then treated overnight with vehicle, 1 μM BNF, or increasing.

DISCUSSION

Herbal medicines are widely used in the United States, with up to one quarter of adults reporting use of such remedies within the past few years. Not surprisingly, the primary physician is often unaware that their patients are using these treatments. The availability and perception that herbal and complementary remedies are safer than prescription medications may have increased the use of these remedies, often leading to self-treatment for a variety of ailments. Failure to recognize side effects of herbal remedies could lead to interactions or unanticipated health consequences. On the other hand, these medicinal agents may have beneficial effects that could be advantageously applied if the mechanisms of action were better understood in the context of Western medicine.

There are several conditions affecting women in which herbal therapies have found a niche. These include menopausal symptoms, menstrual disorders, and treatment for benign conditions, such as endometriosis or uterine fibroids. Many traditional US Food and Drug Administration-approved medications for these conditions have significant side effects or expense. Public concerns about hormone REPLACE ment using commercially available estrogens or progestins have also increased after the Women's Health Initiative studies were published. Pre- and postmenopausal women are thus actively seeking natural or non-traditional medical approaches for a wide variety of complaints.

In the present study, we screened 21 herbs using the alkaline phosphatase assay of Littlefield and co-workers to detect either estrogenic or anti-estrogenic characteristics. PV was the only herbal extract that had strong biological activity in this assay. In review of the literature, there is one report that supports this finding. Huang and colleagues studied the Chinese herb Prunella stica based on its use for the treatment of dysmenorrhea. They showed that this herb blocked the proliferation of Ishikawa cells, but did not interfere with prostaglandin production. Similar to that study, we found that PV extract specifically blocked cell proliferation without affecting cell viability in ECC-1 cells.

The in vivo studies suggest that PV is effective when taken orally, and functions in vivo to block proliferation of ectopic endometrium in response to oestrogen. The apparent reduction in CYR61 and MKI67 expression in the endometriotic implants provides evidence that PV interferes with oestrogen receptor (ESR1) actions.

The ability of PV to block oestrogen action without affecting fecundity in mice suggests that this herb may have advantages for the treatment of women with gynaecologic disease. We and others have pointed out the relationship between elevated oestrogen action and benign endometrial disorders. ESR1 normally declines at the time of implantation, around Cycle Day 19–20 in normal, fertile women. The failure to down-regulate this receptor may be a primary defect leading to altered gene expression patterns seen in endometriosis, or the infertility and pregnancy loss in women with polycystic ovary syndrome. Lack of ESR1 down-regulation is a feature of underlying P resistance seen in some women with benign gynaecologic disease. Methods to block the inappropriate actions of oestrogen during the putative window of implantation could theoretically be helpful and promote improved uterine receptivity toward embryo attachment and implantation. Studies to investigate this possibility are underway.

Understanding the mechanism of the anti-estrogenic activity of PV would likely be informative for the design of improved therapies for endometriosis. There is increasing interest in the role of the AHR pathways regulated by dioxin (2,3,7,8-tetrachlorodibenzo-p-dioxin [TCDD]) and other environmental toxins in endometriosis. Antagonists of AHR found in food are increasingly being studied. Red clover, thought to have SERM-like activities, is also an AHR ligand. The trihydroxystilbene resveratrol, an active component in red wine, appears to have antagonistic actions via AHR. While many natural flavonoids appear to be AHR antagonists and, therefore, inhibit CYP1A1 expression, PV appears to be an AHR agonist with anti-estrogenic properties. Like other herbs noted to inhibit oestrogen, PV uses novel mechanisms to achieve this action. PV appears to activate the AHRE and stimulate AHR target genes in ECC-1 cells. We found little indication that PV had direct effects on ER in endometrial cells.

The mechanism of action of PV to inhibit oestrogen responses, potentially through regulation of AHR, remains elusive. AHR, besides regulating target genes, also interacts with both the androgen and oestrogen receptors, and promotes degradation of these receptors through ubiquitin-mediated mechanisms. Direct action of the AHR to compete with ER activity is another possible explanation for the noted effects of PV on oestrogen activity in vivo and in vitro. In addition, evidence points to regulatory elements of AHR as targets for oestrogen, further complicating this puzzle. Like resveratrol, PV may also act as a competitive antagonist for TCDD, providing yet another beneficial effect of PV on endometriosis in women who consume this herb. Such a mechanism could account for reported improvements in dysmenorrhea seen in women with endometriosis that take PV.

There remains much to learn about herbal and complementary treatments, especially given the potential for cross-reactivity and unintended consequences when taken with other pharmaceuticals. Unrecognized properties of non-traditional therapies, including their actions as AHR ligands, could provide new opportunities for safe and effective treatment of disorders that have not been adequately addressed by conventional Western medical treatments. The discovery of the anti-estrogenic properties of PV provides such an opportunity. This herbal treatment might now be understood at the molecular level as a treatment that blocks oestrogen action in endometriosis, and may protect individuals from environmental factors that favor its development. Unlike resveratrol, found in red wine, which cannot as yet be conveniently consumed by women seeking pregnancy, PV may provide a potent alternative, with potential benefits for both pain and infertility. Further investigation and evaluation of the active component(s) of this herb are currently underway.

REFERENCES

Albertazzi P, Pansini F, Bottazzi M, Bonaccorsi G, de Aloysio D, Morton MS. Dietary soy supplementation and phytoestrogen levels. Obstet Gynecol 1999; 94: 229 231

Amakura Y, Tsutsumi T, Sasaki K, Nakamura M, Yoshida T, Maitani T. Influence of food polyphenols on aryl hydrocarbon receptor-signaling pathway estimated by in vitro bioassay. Phytochemistry 2008; 69: 3117 3130

Antoine C, Liebens F, Carly B, Pastijn A, Rozenberg S. Safety of alternative treatments for menopausal symptoms after breast cancer: a qualitative systematic review. Climacteric 2007; 10: 23 26

Attar E, Bulun SE. Aromatase inhibitors: the next generation of therapeutics for endometriosis? Fertil Steril 2006; 85: 1307 1318

Banerjee, K., & Resat, H. (2015). Constitutive activation of STAT3 in breast cancer cells: A review. International Journal Of Cancer, 138(11), 2570-2578. http://dx.doi.org/10.1002/ijc.29923

Benson, C. S., Babu, S. D., Radhakrishna, S., Selvamurugan, N., & Sankar, B. R. (2013). Expression of matrix metalloproteinases in human breast cancer tissues. Disease markers, 34(6), 395-405.

Berliäre M, Galant C, Donnez J. The potential oncogenic effect of tamoxifen on the endometrium. Hum Reprod 1999; 14: 1381 1383

Biswas, D. K., Shi, Q., Baily, S., Strickland, I., Ghosh, S., Pardee, A. B., & Iglehart, J. D. (2004). NF-kB activation in human breast cancer specimens and its role in cell proliferation and apoptosis. Proceedings of the National Academy of Sciences of the United States of America, 101(27), 10137-10142.

Brzezinski A, Debi A. Phytoestrogens: the “natural” selective oestrogen receptor modulators? Eur J Obstet Gynecol Reprod Biol 1999; 85: 47 51

Budwit-Novotny DA, McCarty KS, Sr, Cox EB, Soper JR, Mutch DG, Creasman WT, Flowers JL, McCarty KS., Jr Immunohistochemical analyses of oestrogen receptor in endometrial adenocarcinoma using a monoclonal antibody. Cancer Res 1986; 46: 5419 5425

Bulun SE, Cheng YH, Yin P, Imir G, Utsunomiya H, Attar E, Innes J, Julie Kim J. Progesterone resistance in endometriosis: link to failure to metabolize oestradiol. Mol Cell Endocrinol 2006; 248: 94 103

Bulun SE, Yang S, Fang Z, Gurates B, Tamura M, Sebastian S. Oestrogen production and metabolism in endometriosis. Ann N Y Acad Sci 2002; 955: 75 85; discussion:86–88; 396–406.

Bulun SE, Zeitoun KM, Takayama K, Sasano H. Oestrogen biosynthesis in endometriosis: molecular basis and clinical relevance. J Mol Endocrinol 2000; 25: 35 42

Burney RO, Talbi S, Hamilton AE, Vo KC, Nyegaard M, Nezhat CR, Lessey BA, Giudice LC. Gene expression analysis of endometrium reveals progesterone resistance and candidate susceptibility genes in women with endometriosis. Endocrinology 2007; 148: 3814 3826

Castro-Rivera E, Wormke M, Safe S. Oestrogen and aryl hydrocarbon responsiveness of ECC-1 endometrial cancer cells. Mol Cell Endocrinol 1999; 150: 11 21

Chen ZH, Hurh YJ, Na HK, Kim JH, Chun YJ, Kim DH, Kang KS, Cho MH, Surh YJ. Resveratrol inhibits TCDD-induced expression of CYP1A1 and CYP1B1 and catechol oestrogen-mediated oxidative DNA damage in cultured human mammary epithelial cells. Carcinogenesis 2004; 25: 2005 2013

Chiu LC, Zhu W, Ooi VE. A polysaccharide fraction from medicinal herb Prunella vulgaris down regulates the expression of herpes simplex virus antigen in Vero cells. J Ethnopharmacol 2004; 93: 63 68

Collins NH, Lessey EC, DuSell CD, et al. (2009). Characterization of Antioestrogenic Activity of the Chinese Herb, Prunella vulgaris, Using In Vitro and In Vivo (Mouse Xenograft) Models. Biol Reprod, 80(2): 375–383. doi:  10.1095/biolreprod.107.065375

Cuellar N, Aycock T, Cahill B, Ford J. Complementary and alternative medicine (CAM) use by African American (AA) and Caucasian American (CA) older adults in a rural setting: a descriptive, comparative study. BMC Complement Altern Med 2003; 3: 8

Daniel Y, Inbar M, Bar-Am A, Peyser MR, Lessing JB. The effects of tamoxifen treatment on the endometrium. Fertil Steril 1996; 65: 1083 1089

Davis RN. Alternatives to hormone therapy: a clinical guide to menopausal transition. Adv Nurse Pract 2004; 12: 37 38

Dawood MY, Ramos J, Khan-Dawood FS. Depot leuprolide acetate versus danazol for treatment of pelvic endometriosis: changes in vertebral bone mass and serum oestradiol and calcitonin. Fertil Steril 1995; 63: 1177 1183

Donaghay M, Lessey BA. Uterine receptivity: alterations associated with benign gynecological disease. Semin Reprod Med 2007; 25: 461 475

Fazleabas AT, Brudney A, Chai D, Langoi D, Bulun SE. Steroid receptor and aromatase expression in baboon endometriotic lesions. Fertil Steril 2003; 80 (suppl 2): 820 827

Feng L, Jia X, Zhu M, et al. Chemoprevention by Prunella vulgaris L. extract of non-small cell lung cancer via promoting apoptosis and regulating the cell cycle. Asian Pac J Cancer Prev. 2010;11(5):1355-8.

Gasiewicz TA, Rucci G. Alpha-naphthoflavone acts as an antagonist of 2,3,7, 8-tetrachlorodibenzo-p-dioxin by forming an inactive complex with the Ah receptor. Mol Pharmacol 1991; 40: 607 612

Gaudet T. Complementary and Alternative Medicine. Clinical Updates in Women's Health Care 2004; III: 1 82

Geller SE, Studee L. Botanical and dietary supplements for mood and anxiety in menopausal women. Menopause 2007; 14: 541 549

Giannelli M, Cuttini M, Da Fre M, Buiatti E. General practitioners' knowledge and practice of complementary/alternative medicine and its relationship with life-styles: a population-based survey in Italy. BMC Fam Pract 2007; 8: 30

Greenberg LH, Slayden OD. Human endometriotic xenografts in immunodeficient RAG-2/gamma(c)KO mice. Am J Obstet Gynecol 2004; 190: 1788 1795; discussion:1795–1796.

Gregory CW, Wilson EM, Apparao KB, Lininger RA, Meyer WR, Kowalik A, Fritz MA, Lessey BA. Steroid receptor coactivator expression throughout the menstrual cycle in normal and abnormal endometrium. J Clin Endocrinol Metab 2002; 87: 2960 2966

Huang JC, Ruan CH, Tang K, Ruan KH. Prunella stica inhibits the proliferation but not the prostaglandin production of Ishikawa cells. Life Sci 2006; 79: 436 441

Huang M, Wang Y, Xu L, You M. Anti-tumor Properties of Prunella vulgaris. Curr Pharmacol Rep (2015) 1:401–419 DOI 10.1007/s40495-015-0038-6

Hunter DS, Hodges LC, Eagon PK, Vonier PM, Fuchs-Young R, Bergerson JS, Walker CL. Influence of exogenous oestrogen receptor ligands on uterine leiomyoma: evidence from an in vitro/in vivo animal model for uterine fibroids. Environ Health Perspect 2000; 108 (suppl 5): 829 834

Hwang YJ, Lee EJ, Kim HR, Hwang KA. In vitro antioxidant and anticancer effects of solvent fractions from Prunella vulgaris var. lilacina.BMC Complement Altern Med. 2013 Nov 9;13:310. doi: 10.1186/1472-6882-13-310.

Jackson KS, Brudney A, Hastings JM, Mavrogianis PA, Kim JJ, Fazleabas AT. The altered distribution of the steroid hormone receptors and the chaperone immunophilin FKBP52 in a baboon model of endometriosis is associated with progesterone resistance during the window of receptivity. Reprod Sci 2007; 14: 137 150

Jacobson JS, Workman SB, Kronenberg F. Research on complementary and alternative therapies for cancer: issues and methodological considerations. J Am Med Womens Assoc 1999; 54: 177 180

Kageyama S, Kurokawa M, Shiraki K. Extract of Prunella vulgaris spikes inhibits HIV replication at reverse transcription in vitro and can be absorbed from intestine in vivo. Antivir Chem Chemother 2000; 11: 157 164

Karin, M. (2006). Nuclear factor-kB in cancer development and progression. Nature, 441(7092), 431-436. http://dx.doi.org/10.1038/nature04870

Kim H-I, Quan F-S, Kim J-E et al. Inhibition of oestrogen signaling through depletion of oestrogen receptor alpha by ursolic acid and betulinic acid from Prunella vulgaris var. lilacina. Biochemical and Biophysical Research Communications. Volume 451, Issue 2, 22 August 2014, Pages 282–287

Kim, H., Quan, F., Kim, J., Lee, N., Kim, H., & Jo, S. et al. (2014). Inhibition of oestrogen signaling through depletion of oestrogen receptor alpha by ursolic acid and betulinic acid from Prunella vulgaris var. lilacina. Biochemical And Biophysical Research Communications, 451(2), 282-287.

http://dx.doi.org/10.1016/j.bbrc.2014.07.115

Kim, J., Jung, H., Ahn, S., Bae, S., Lee, S., & Kim, S. et al. (2016). The relationship between nuclear factor (NF)-kB family gene expression and prognosis in triple-negative breast cancer (TNBC) patients receiving adjuvant doxorubicin treatment. Scientific Reports, 6(1). http://dx.doi.org/10.1038/srep31804

Lee, H., Pal, S., Reckamp, K., Figlin, R., & Yu, H. (2010). STAT3: A Target to Enhance Antitumor Immune Response. Current Topics In Microbiology And Immunology, 344, 41-59. http://dx.doi.org/10.1007/82_2010_51

Lessey BA, Killam AP, Metzger DA, Haney AF, Greene GL, McCarty KS., Jr Immunohistochemical analysis of human uterine oestrogen and progesterone receptors throughout the menstrual cycle. J Clin Endocrinol Metab 1988; 67: 334 340

Lessey BA, Palomino WA, Apparao KB, Young SL, Lininger RA. Oestrogen receptor-alpha (ER-alpha) and defects in uterine receptivity in women. Reprod Biol Endocrinol 2006; 4 (suppl 1): S9

Lessey BA. Medical management of endometriosis and infertility. Fertil Steril 2000; 73: 1089 1096

Li, W., Zhang, H., Nie, M., Tian, Y., Chen, X., & Chen, C. et al. (2017). Ursolic acid derivative FZU-03,010 inhibits STAT3 and induces cell cycle arrest and apoptosis in renal and breast cancer cells. Acta Biochimica Et Biophysica Sinica, 49(4), 367-373. http://dx.doi.org/10.1093/abbs/gmx012

Liang, M., Zhang, P., & Fu, J. (2007). Up-regulation of LOX-1 expression by TNF-α promotes trans-endothelial migration of MDA-MB-231 breast cancer cells. Cancer Letters, 258(1), 31-37. http://dx.doi.org/10.1016/j.canlet.2007.08.003

Littlefield BA, Gurpide E, Markiewicz L, McKinley B, Hochberg RB. A simple and sensitive microtiter plate oestrogen bioassay based on stimulation of alkaline phosphatase in Ishikawa cells: estrogenic action of delta 5 adrenal steroids. Endocrinology 1990; 127: 2757 2762

MacLaughlin SD, Palomino WA, Mo B, Lewis TD, Lininger RA, Lessey BA. Endometrial expression of Cyr61: a marker of oestrogen activity in normal and abnormal endometrium. Obstet Gynecol 2007; 110: 146 154

Majumdar SR, Almasi EA, Stafford RS. Promotion and prescribing of hormone therapy after report of harm by the Women's Health Initiative. JAMA 2004; 292: 1983 1988

Medjakovic S, Jungbauer A. Red clover isoflavones biochanin A and formononetin are potent ligands of the human aryl hydrocarbon receptor. J Steroid Biochem Mol Biol 2008; 108: 171 177

Meehye, K. (2012). The effect of Prunella on anti-inflammatory activity in RAW264. 7 mouse macrophage cells. Food and Nutrition Sciences, 2012.

Mikail CN, Hearney E, Nemesure B. Increasing physician awareness of the common uses and contraindications of herbal medicines: utility of a case-based tutorial for residents. J Altern Complement Med 2003; 9: 571 576

Mishra K, Wadhwa N, Guleria K, Agarwal S. ER, PR and Ki-67 expression status in granulomatous and chronic non-specific endometritis. J Obstet Gynaecol Res 2008; 34: 371 378

Mizrachi N, Shuval JT, Gross S. Boundary at work: alternative medicine in biomedical settings. Sociol Health Illn 2005; 27: 20 43

Mo B, Vendrov AE, Palomino WA, DuPont BR, Apparao KB, Lessey BA. ECC-1 cells: a well-differentiated steroid-responsive endometrial cell line with characteristics of luminal epithelium. Biol Reprod 2006; 75: 387 394

Nakshatri, H., Bhat-Nakshatri, P., Martin, D., Goulet, R., & Sledge, G. (1997). Constitutive activation of NF-kappaB during progression of breast cancer to hormone-independent growth. Molecular And Cellular Biology, 17(7), 3629-3639. http://dx.doi.org/10.1128/mcb.17.7.3629

Nestler G, Dovey M. Traditional Chinese medicine. Clin Obstet Gynecol 2001; 44: 801 813

Ohtake F, Baba A, Fujii-Kuriyama Y, Kato S. Intrinsic AhR function underlies cross-talk of dioxins with sex hormone signalings. Biochem Biophys Res Commun 2008; 370: 541 546

Palomba S, Orio F, Jr, Russo T, Falbo A, Tolino A, Lombardi G, Cimini V, Zullo F. Antiproliferative and proapoptotic effects of raloxifene on uterine leiomyomas in postmenopausal women. Fertil Steril 2005; 84: 154 161

Pikarsky, E., Porat, R., Stein, I., Abramovitch, R., Amit, S., & Kasem, S. et al. (2004). NF-kB functions as a tumor promoter in inflammation-associated cancer. Nature, 431(7007), 461-466. http://dx.doi.org/10.1038/nature02924

Pinn G. Herbs used in obstetrics and gynaecology. Aust Fam Physician 2001; 30: 351 354

Psotova J, Kolar M, Sousek J, Svagera Z, Vicar J, Ulrichova J. Biological activities of Prunella vulgaris extract. Phytother Res 2003; 17: 1082 1087

Psotova J, Svobodova A, Kolarova H, Walterova D. Photoprotective properties of Prunella vulgaris and rosmarinic acid on human keratinocytes. J Photochem Photobiol B 2006; 84: 167 174

Rier S, Foster WG. Environmental dioxins and endometriosis. Toxicol Sci 2002; 70: 161 170

Rossouw JE, Anderson GL, Prentice RL, LaCroix AZ, Kooperberg C, Stefanick ML, Jackson RD, Beresford SA, Howard BV, Johnson KC, Kotchen JM, Ockene J. Risks and benefits of oestrogen plus progestin in healthy postmenopausal women: principal results from the Women's Health Initiative randomized controlled trial. JAMA 2002; 288: 321 333

Ryu, S., Oak, M., Yoon, S., Cho, D., Yoo, G., Kim, T., & Kim, K. (2000). Anti-Allergic and Anti-Inflammatory Triterpenes from the Herb of Prunella vulgaris. Planta Medica, 66(4), 358-360. http://dx.doi.org/10.1055/s-2000-
